Wire Rope Hoists
Liftsafe Engineering offers many different brands, capacities, lifts, and options for wire rope hoists. Wire Rope Hoists are ideal for construction, maintenance, and industrial applications with exceptional durability and reliability. Our specialists are here to help find the right wire rope hoist for your facility or customize a solution for unique applications.
What to expect from OHSA
GH Wire Rope Hoists
GH wire rope hoists, for bridge, gantry and semi-gantry cranes, single and double girder, and other types of applications. These wire rope hoists incorporate frequency inverters to their hoist and cross travel movement as a standard feature. This feature also prevents hazardous swing, improves motor protection and extends the working life of the motors and other crane mechanisms, resulting in decreased maintenance costs. The range of GH hoists have been designed with the following principles; reliability, security, durability, price and easy maintenance.
- Equipment capacity, speed and lift details available upon request.
- All hoist and crane products are not available for direct sale through featured suppliers.
- Liftsafe Engineering is a stocking dealer (with exclusivity in Ontario and Quebec) of all GH products and offers competitive pricing and delivery timelines to our clients.
- Liftsafe Engineering can service the entire lifecycle of your product. From start to finish, we design, build, inspect, and maintain.
Capacity | Part Number | Speed (m/min) | Duty FEM | Height of lift 1 | Height of lift 2 | Height of lift 3 | Falls | |
---|---|---|---|---|---|---|---|---|
1,000 kg | GHA12_014105M7 | 5 | M7 | 4.5 | 8 | 1/9 | 4/1 | Request a Quote |
GHA12_012110M6 | 10 | M6 | 9 | 16 | 1/20 | 2/1 | Request a Quote | |
GHB11_011116M7 | 16 | M7 | 14.5 | 27.1 | 2/5 | 1/1 | Request a Quote | |
GHB11_012216M7 | 16 | M7 | 4 | 10.3 | 1/14 | 2/2 | Request a Quote | |
GHB11_011120M6 | 20 | M6 | 14.5 | 27.1 | 2/5 | 1/1 | Request a Quote | |
GHB11_012220M6 | 20 | M6 | 4 | 10.3 | 15.4 | 2/2 | Request a Quote | |
Customizations available | ||||||||
1,600 kg | GHA12_014105M7 | 5 | M7 | 4.5 | 8 | 1/9 | 4/1 | Request a Quote |
GHA12_012110M5 | 10 | M5 | 9 | 16 | 1/20 | 2/1 | Request a Quote | |
GHB11_012216M5 | 16 | M5 | 10.3 | 1/14 | 2/2 | Request a Quote | ||
GHB11_011116M5 | 16 | M5 | 14.5 | 27.1 | 2/5 | 1/1 | Request a Quote | |
GHD13_012220M7 | 20 | M7 | 15.9 | 2/2 | Request a Quote | |||
GHD13_011120M7 | 20 | M7 | 15.2 | 28.8 | 1/1 | Request a Quote | ||
Customizations available | ||||||||
2,000 Kg | GHA12_024105M7 | 5 | M7 | 4.5 | 8 | 1/9 | 4/1 | Request a Quote |
GHB11_022108M7 | 8 | M7 | 7.26 | 13.55 | 1/17 | 2/1 | Request a Quote | |
GHB11_024208M7 | 8 | M7 | 5 | 1/6 | 4/2 | Request a Quote | ||
GHB11_022110M6 | 10 | M6 | 7.26 | 13.55 | 1/17 | 2/1 | Request a Quote | |
GHB11_024210M6 | 10 | M6 | 5 | 1/6 | 4/2 | Request a Quote | ||
GHD13_022216M7 | 16 | M7 | 15.9 | 2/2 | Request a Quote | |||
GHD13_021116M7 | 16 | M7 | 15.2 | 28.8 | 1/1 | Request a Quote | ||
GHD13_022220M6 | 20 | M6 | 15.9 | 2/2 | Request a Quote | |||
GHD13_021120M6 | 20 | M6 | 15.2 | 28.8 | 1/1 | Request a Quote | ||
Customizations available | ||||||||
2,500 kg | GHA12_024105M6 | 5 | M6 | 4.5 | 8 | 1/9 | 4/1 | Request a Quote |
GHB11_022108M6 | 8 | M6 | 7.26 | 13.55 | 1/17 | 2/1 | Request a Quote | |
GHB11_024208M6 | 8 | M6 | 5 | 1/6 | 4/2 | Request a Quote | ||
GHB11_022110M5 | 10 | M5 | 7.26 | 13.55 | 1/17 | 2/1 | Request a Quote | |
GHB11_024210M5 | 10 | M5 | 5 | 1/6 | 4/2 | Request a Quote | ||
GHD13_022110M7 | 10 | M7 | 7.6 | 14.4 | 2/1 | Request a Quote | ||
GHD13_024210M7 | 10 | M7 | 7 | 4/2 | Request a Quote | |||
GHD13_022216M6 | 16 | M6 | 15.9 | 2/2 | Request a Quote | |||
GHD13_021116M6 | 16 | M6 | 15.2 | 28.8 | 1/1 | Request a Quote | ||
GHD13_022220M5 | 20 | M5 | 15.9 | 2/2 | Request a Quote | |||
GHD13_021120M5 | 20 | M5 | 15.2 | 28.8 | 1/1 | Request a Quote | ||
Customizations available | ||||||||
3,200 Kg | GHA12_034105M5 | 5 | M5 | 4.5 | 8 | 1/9 | 4/1 | Request a Quote |
GHB11_034105M7 | 5 | M7 | 3.6 | 6.8 | 4/1 | Request a Quote | ||
GHB11_032108M5 | 8 | M5 | 7.26 | 13.55 | 1/17 | 2/1 | Request a Quote | |
GHB11_034208M5 | 8 | M5 | 5 | 1/6 | 4/2 | Request a Quote | ||
GHD13_032110M7 | 10 | M7 | 7.6 | 14.4 | 2/1 | Request a Quote | ||
GHD13_034210M7 | 10 | M7 | 7 | 4/2 | Request a Quote | |||
GHD13_032216M5 | 16 | M5 | 15.9 | 2/2 | Request a Quote | |||
GHD13_031116M5 | 16 | M5 | 15.2 | 28.8 | 1/1 | Request a Quote | ||
Customizations available | ||||||||
4,000 Kg | GHB11_044104M7 | 4 | M7 | 3.6 | 6.8 | 4/1 | Request a Quote | |
GHB11_044105M6 | 5 | M6 | 3.6 | 6.8 | 4/1 | Request a Quote | ||
GHD13_042108M7 | 8 | M7 | 7.6 | 14.4 | 2/1 | Request a Quote | ||
GHD13_044208M7 | 8 | M7 | 7 | 4/2 | Request a Quote | |||
GHD13_042110M6 | 10 | M6 | 7.6 | 14.4 | 2/1 | Request a Quote | ||
GHD13_044210M6 | 10 | M6 | 7 | 4/2 | Request a Quote | |||
Customizations available | ||||||||
5,000 kg | GHB11_054104M6 | 4 | M6 | 3.6 | 6.8 | 4/1 | Request a Quote | |
GHB11_054105M5 | 5 | M5 | 3.6 | 6.8 | 4/1 | Request a Quote | ||
GHD13_054105M7 | 5 | M7 | 3.8 | 7.2 | 4/1 | Request a Quote | ||
GHD13_052108M6 | 8 | M6 | 7.6 | 14.4 | 2/1 | Request a Quote | ||
GHD13_054208M6 | 8 | M6 | 7 | 4/2 | Request a Quote | |||
GHD13_052110M5 | 10 | M5 | 7.6 | 14.4 | 2/1 | Request a Quote | ||
GHD13_054210M5 | 10 | M5 | 7 | 4/2 | Request a Quote | |||
Customizations available | ||||||||
6,300 kg | GHB11_064104M5 | 4 | M5 | 3.6 | 6.8 | Request a Quote | ||
GHD13_064105M7 | 5 | M7 | 3.8 | 7.2 | Request a Quote | |||
GHD13_062108M5 | 8 | M5 | 7.6 | 14.4 | Request a Quote | |||
GHD13_064208M5 | 8 | M5 | 7 | Request a Quote | ||||
Customizations available | ||||||||
8,000 kg | GHD13_084104M7 | 4 | M7 | 3.8 | 7.2 | 4/1 | Request a Quote | |
GHD13_084105M6 | 5 | M6 | 3.8 | 7.2 | 4/1 | Request a Quote | ||
Customizations available | ||||||||
10,000 kg | GHD13_104104M6 | 4 | M6 | 3.8 | 7.2 | 4/1 | Request a Quote | |
GHD13_104105M5 | 5 | M5 | 3.8 | 7.2 | 4/1 | Request a Quote | ||
Customizations available | ||||||||
12,500 kg | GHD13_124104M5 | 4 | M5 | 3.8 | 7.2 | 10 | 4/1 | Request a Quote |
Customizations available |
Yale Wire Rope Hoists
Yale hoists have a reputation for superior performance, low maintenance, and longevity in heavy-duty applications. Yale Hoists are highly customizable hoist and can be optimized for your specific application requirements. Yale represents one of the most popular brands in the material handling industry, with users specifying it for applications ranging from offshore oil platforms to pulp and paper production. Known for a wide range of wire rope products, the Yale brand stands for top quality and performance.
- Equipment capacity, speed and lift details available upon request.
- All hoist and crane products are not available for direct sale through featured suppliers.
- Liftsafe Engineering is an authorized dealer of all Yale products and offers competitive pricing and customization to our clients.
- Liftsafe Engineering can service the entire lifecycle of your product. From start to finish, we design, build, inspect, and maintain.
Product name | Capacity | Lifting speed (fpm) | Lift | Reeve | Additional Information | |||
---|---|---|---|---|---|---|---|---|
Yale Cable King Electric Wire Rope Hoist | 7 1/2 tons – 25 tons | 11 – 46 FPM | 38 – 256 ft | Double and single available | Ideal for use in both standard industrial and hazardous environments. | Request a Quote | ||
Yale Global King | 1 – 15 tons | 18/4.5 FPM – 40/10 FPM | 20 – 80 ft | 2 part and 4 part reeve models available | Request a Quote | |||
Yale YK Wire Rope Hoists | 1-30 tons | 80/20 fpm | up to 131 ft | 2 part single or 4 part single reeving is available | Request a Quote | |||
Yale Y80 Wire Rope Hoist | 1/2 ton – 5 tons | 8-48 fpm | 20-60 ft | Single reeved and true vertical lift | Request a Quote | |||
Yale lodeking LT Electric Wire Rope Hoist | 10-25 tons | 9-21 fpm | 23-49 ft | Request a Quote | ||||
Customizations available |
Shaw-Box Wire Rope Hoists
Shaw-Box wire rope hoists represent a long line of innovation in the material handling industry that dates back to the late 1800s. Shaw-Box products are known for their quality and performance. Whether the job calls for electric or air-power, indoor or outdoor duty, general or severe industrial service, a Shaw-Box product meets the needs of your facility and workers.
- Equipment capacity, speed and lift details available upon request.
- All hoist and crane products are not available for direct sale through featured suppliers.
- Liftsafe Engineering is an authorized dealer of all Shaw Box products and offers competitive pricing and customization to our clients.
- Liftsafe Engineering can service the entire lifecycle of your product. From start to finish, we design, build, inspect, and maintain.
Product name | Capacity | Lifting speed (fpm) | Lift | Reeve | Suspension | |||
---|---|---|---|---|---|---|---|---|
Shaw-box SK wire rope hoist | 1-55 tons | 3.3-20 fpm | 20′ – 93′ feet | 2 part single or 4-part single reeving | Request a Quote | |||
Shaw box 800 series electric wire rope hoists and trolley | 1-25 tons | 8-48 fpm | 20-60 feet | Single speed, Two speed, Variable Frequency Control | Request a Quote | |||
Shaw box 700 series electric wire rope hoists and trolley | 1-25 tons | 8-56 fpm | 18-259 feet | Single speed, Two speed, Variable Frequency Control | Lug, Push Trolley, Hand Geared Trolley, Motor Driven Trolley, Deck and Base | Request a Quote | ||
Customizations available |
R&M Wire Rope Hoists
With 90 years of developing and perfecting crane packages, electric chain hoists, and wire rope hoists, R&M is ready to help your business rise above your material handling challenges. R&M Wire Rope Hoists come standard with everything you need to work quickly and safely. Their hoists can meet your every lifting demand and come in configurations including normal headroom, low headroom and double girder designs.
- Equipment capacity, speed and lift details available upon request.
- All hoist and crane products are not available for direct sale through featured suppliers.
- Liftsafe Engineering is an authorized dealer of all R&M products and offers competitive pricing and customization to our clients.
- Liftsafe Engineering can service the entire lifecycle of your product. From start to finish, we design, build, inspect, and maintain.
Product Name | Capacity | Lifting speed | Lift/Hz Supply | Reeve | ||||
---|---|---|---|---|---|---|---|---|
Spacemaster SX Wire Rope Hoist | 1/2 ton-80 tons | 10/1.5-62/10 fpm | 13-320 ft 208, 230, 460, 575/3/60 or 380/3/50 power supply | Single reeved or double reeved | Request a Quote | |||
Spacemaster EX class 1, DIV 1 Hoist | 5-20 tons | Two-speed hoist with 6:1 ratio | 460 or 575/3/60Hz supply | Single reeved or double reeved | Request a Quote | |||
Spacemaster EX class 1, DIV 2 Hoist | 1.5 – 80 ton | Two-speed hoist with 6:1 ratio | 460, 575/3/60 Hz or 380/3/50 Hz supply | Single reeved or double reeved | Request a Quote | |||
Customizations available |
Stahl Wire Rope Hoists
STAHL Crane Systems are known for quality, reliability and performance. Their products are used in standard, custom and explosion-proof cranes and lifting systems in industries ranging from metals production to mining and offshore oil and gas. STAHL Wire Rope Hoists are compact, powerful and particularly maintenance-friendly. You can rely on their industry-leading engineering expertise to create products that meet even the most complex.
- Equipment capacity, speed and lift details available upon request.
- All hoist and crane products are not available for direct sale through featured suppliers.
- Liftsafe Engineering is an authorized dealer of all Stahl products and offers competitive pricing and customization to our clients.
- Liftsafe Engineering can service the entire lifecycle of your product. From start to finish, we design, build, inspect, and maintain.
Product name | Capacity | Lift | Certification | Additional features | ||||
---|---|---|---|---|---|---|---|---|
Stahl SH Wire rope hoists | 500 – 32000 kg | Lifting hieghts from 6-30 metres available | SH wire rope hoist can be designed to meet ATEX/IECEx Zone 1, Zone 2, Zone 21 or Zone 22 as well as NEC and CEC Class I Division 1 and Class I Division 2 requirements. | Available in explosion-proof design | Request a Quote | |||
SH 6080 wire rope hoist | 20000- 32000 kg | Lifting hieghts from 6-30 metres available | SH wire rope hoist can be designed to meet ATEX/IECEx Zone 1, Zone 2, Zone 21 or Zone 22 as well as NEC and CEC Class I Division 1 and Class I Division 2 requirements. | Available in explosion-proof design | Request a Quote | |||
AS 7 wire rope hoist | 32000-125000 kg | Optionally available in explosionprotected design complying with ATEX and IECEx | Available in explosion-proof design | Request a Quote | ||||
LNG wire rope hoists | The engineering solution for liquified natural gas trains and LNG terminals in four safety levels – Custom options available upon request | Request a Quote | ||||||
Customizations available |
